How to print debug text in Gear VR ?

11 replies
6464 views

All tutorials/examples online for Unity C# code are made for conventional screens. So am sure there will be an issue using standard debug print functionality.

I wonder how to print debug text in Gear VR ?

Thanks.

This topic has been closed for replies.

C

cybereality

Inspiring

You should be able to still use Log statements, I believe (at least it appears that way after a quick search).

See this thread I found: http://forum.unity3d.com/threads/is-it- ... le.339572/

O

owenwp

Up and Coming

If you mean on screen, you will need to make your own UI that displays log text. Unity has a log callback function you can use to get logged messages.

M

motorsepAuthor

Inspiring

"owenwp" wrote:
If you mean on screen, you will need to make your own UI that displays log text. Unity has a log callback function you can use to get logged messages.

That would be lovely. I miss that kind of direct feedback from Quakes and Doom 3 :)

Is it a trivial task to accomplish? Any idea if some ready to be used code (or at least tutorial) available somewhere ?

O

owenwp

Up and Coming

The new Unity UI system has the ability to place canvases in world space, and there are a bunch of video tutorials on their site. The simplest approach would be to just make a big text label and give it a formatted string. You should be able to piece it together from the samples in the docs.

G

guigou

New Participant

Here is what I'm using:


using UnityEngine;
using System.Collections.Generic;
using System.Linq;
using UnityEngine.UI;

static class OVRDebug {
	private static List<string> logs = new List<string> ();
	private static Text text;
	public static int nLogs = 10; // max number of lines to display. Can be changed


	static OVRDebug() {
		// will only be called once
		OVRCameraRig oVRCamera = GameObject.FindObjectOfType<OVRCameraRig> ();
		if (oVRCamera == null) {
			Debug.Log("Missing OVR camera");
			return;
		}
		// create a canvas and a text element to display the logs
		GameObject goCanvas = new GameObject ("Canvas");
		goCanvas.transform.parent = oVRCamera.gameObject.transform;
		goCanvas.transform.position = new Vector3(0, 4, -4); // arbitrary, works well for me

		Canvas canvas = goCanvas.AddComponent<Canvas> ();
		canvas.renderMode = RenderMode.WorldSpace;

		GameObject goText = new GameObject ("Text");
		goText.transform.parent = goCanvas.transform;
		goText.transform.position = Vector3.zero;
		text = goText.AddComponent<Text> ();
		text.font = Resources.GetBuiltinResource<Font> ("Arial.ttf");
		text.fontSize = 30;
		text.color = Color.black;
		RectTransform tr = goText.GetComponent<RectTransform> ();
		tr.localScale = new Vector3 (0.01f, 0.01f, 0.01f);
		tr.sizeDelta = new Vector2 (1000, 1000);
	}

	public static void Log(object log) {
		if (text == null) {
			// No OVR camera, fallback to normal logging
			Debug.Log(log);
			return;
		}
		// add the log to the queue
		string s = log.ToString ();
		logs.Add (s);
		// make sure we don't keep too many logs
		if (logs.Count > nLogs)
			logs.RemoveAt(0);
		PrintLogs ();
	}

	private static void PrintLogs () {
		string s = "";
		foreach (string k in logs) {
			s += k + "\n";
		}
		text.text = s;
	}
}

And then I can call OVRDebug.Log (...) from anywhere.
It works well, excepted when there are objects in between :)

P

peterept

Up and Coming

I wrote a script which broadcasts all Debug logs over the WiFi network.

I use it all the time for tracing on GearVR. It's quicker and easier then messing about with ADB.

To use it:

1. Create a game object, and drag on the DebugLogBroadcaster.cs script

2. Install a UDP server on your Windows, such as:
SocketTest
http://sourceforge.net/projects/sockettest
Launch it, go to UDP tab, set port to 9999 and press Start Listening.

3. IF you want to see stack traces, checkmark "Development Build" in build settings

Now, when you run your app on GearVR and it's on the same network, you'll receive all debug logs.

Good luck,

Peter

using UnityEngine;
using System;
using System.Text;
using System.Net.Sockets;
using System.Net;

/*
 * Broadcast all Debug Log messages on the current WiFi network
 * By Peter Koch <peterept@gmail.com>
 *
 * Useful for debugging GearVR builds over WiFi
 *
 * Use this with any UDP Listener on your PC
 * eg: SocketTest
 *     http://sourceforge.net/projects/sockettest/
 *     Launch the app, go to UDP tab, set port to 9999 and press Start Listening
 *
 * Important Note:
 *  - Callstacks are only sent in non-editor builds when "Development Build" is checkmarked in Build Settings
 */
public class DebugLogBroadcaster : MonoBehaviour
{
	public int broadcastPort = 9999;

	IPEndPoint remoteEndPoint;
	UdpClient client;

	void OnEnable()
	{
		remoteEndPoint = new IPEndPoint(IPAddress.Broadcast, broadcastPort);
		client = new UdpClient();
		Application.logMessageReceived += HandlelogMessageReceived;
	}

	void OnDisable()
	{
		Application.logMessageReceived -= HandlelogMessageReceived;
		client.Close();
		remoteEndPoint = null;
	}

	void HandlelogMessageReceived (string condition, string stackTrace, LogType type)
	{
		string s = stackTrace.Replace ("\n", "\n  ");

		string msg = string.Format ("[{0}] {1}{2}",
		                           type.ToString ().ToUpper (),
		                           condition,
		                           "\n    " + stackTrace.Replace ("\n", "\n    "));
		byte[] data = Encoding.UTF8.GetBytes(msg);
		client.Send(data, data.Length, remoteEndPoint);
	}
}

Check out my Unity VR development blog: http://talesfromtherift.com @peterept

DebugLogBroadcaster.zip

M

motorsepAuthor

Inspiring

Cool stuff Peter, thanks a bunch!

Btw, I sent you an e-mail.

G

guneyozsan

New Participant

guigou said:

Here is what I'm using:

using UnityEngine;
using System.Collections.Generic;
using System.Linq;
using UnityEngine.UI;

static class OVRDebug {
	private static List&lt;string&gt; logs = new List&lt;string&gt; ();
	private static Text text;
	public static int nLogs = 10; // max number of lines to display. Can be changed


	static OVRDebug() {
		// will only be called once
		OVRCameraRig oVRCamera = GameObject.FindObjectOfType&lt;OVRCameraRig&gt; ();
		if (oVRCamera == null) {
			Debug.Log("Missing OVR camera");
			return;
		}
		// create a canvas and a text element to display the logs
		GameObject goCanvas = new GameObject ("Canvas");
		goCanvas.transform.parent = oVRCamera.gameObject.transform;
		goCanvas.transform.position = new Vector3(0, 4, -4); // arbitrary, works well for me

		Canvas canvas = goCanvas.AddComponent&lt;Canvas&gt; ();
		canvas.renderMode = RenderMode.WorldSpace;

		GameObject goText = new GameObject ("Text");
		goText.transform.parent = goCanvas.transform;
		goText.transform.position = Vector3.zero;
		text = goText.AddComponent&lt;Text&gt; ();
		text.font = Resources.GetBuiltinResource&lt;Font&gt; ("Arial.ttf");
		text.fontSize = 30;
		text.color = Color.black;
		RectTransform tr = goText.GetComponent&lt;RectTransform&gt; ();
		tr.localScale = new Vector3 (0.01f, 0.01f, 0.01f);
		tr.sizeDelta = new Vector2 (1000, 1000);
	}

	public static void Log(object log) {
		if (text == null) {
			// No OVR camera, fallback to normal logging
			Debug.Log(log);
			return;
		}
		// add the log to the queue
		string s = log.ToString ();
		logs.Add (s);
		// make sure we don't keep too many logs
		if (logs.Count &gt; nLogs)
			logs.RemoveAt(0);
		PrintLogs ();
	}

	private static void PrintLogs () {
		string s = "";
		foreach (string k in logs) {
			s += k + "\n";
		}
		text.text = s;
	}
}

And then I can call OVRDebug.Log (...) from anywhere.

It works well, excepted when there are objects in between :)

You can overcome "objects in between" by putting debug objects to another layer and assigning a camera that renders only that layer with a large depth (say 100).
