MovieTexture on Gear VR
Hello guys, I know that MovieTexture don't work to Android and the plugin EasyMovieTexture don't work to Gear VR
On Oculus SDK has a script called MoviePlayerSample.cs, and I'm trying to use it, but I don't know if i'm doing right, because I follow the instructions and when I build the video dont play. I tryied to use the example scene to but it still dont play: Thats what I done:
(Instructions by the developper):
" Place a simple textured quad surface with the correct aspect ratio in your scene.
Add the MoviePlayerSample.cs script to the surface object.
Modify it for the correct media location (currently hardcoded)
Modify it to start when you want, instead of on the very first Update()."
On the third instruction that need to modify the media location I changed the line of the example code to this:
And I done the other instructions too I just don't know if the last instruction works and if I done right on the third instruction.
I will send the developper code from sdk with my changes to be easy to understand:
On Oculus SDK has a script called MoviePlayerSample.cs, and I'm trying to use it, but I don't know if i'm doing right, because I follow the instructions and when I build the video dont play. I tryied to use the example scene to but it still dont play: Thats what I done:
(Instructions by the developper):
" Place a simple textured quad surface with the correct aspect ratio in your scene.
Add the MoviePlayerSample.cs script to the surface object.
Modify it for the correct media location (currently hardcoded)
Modify it to start when you want, instead of on the very first Update()."
On the third instruction that need to modify the media location I changed the line of the example code to this:
mediaPlayer.Call("setDataSource", "/Card/oculus/Movies/Trailers/Interstellar.mp4");And I done the other instructions too I just don't know if the last instruction works and if I done right on the third instruction.
I will send the developper code from sdk with my changes to be easy to understand:
/************************************************************************************
Filename : MoviePlayerSample.cs
Content : An example of how to use the Moonlight video player
Created : July 12, 2014
Copyright : Copyright 2014 Oculus VR, LLC. All Rights reserved.
Use of this software is subject to the terms of the Oculus LLC license
agreement provided at the time of installation or download, or which
otherwise accompanies this software in either electronic or hard copy form.
************************************************************************************/
using UnityEngine;
using System.Collections; // required for Coroutines
using System.Runtime.InteropServices; // required for DllImport
using System; // requred for IntPtr
/************************************************************************************
Usage:
Place a simple textured quad surface with the correct aspect ratio in your scene.
Add the MoviePlayerSample.cs script to the surface object.
Modify it for the correct media location (currently hardcoded)
Modify it to start when you want, instead of on the very first Update().
Implementation:
In the MoviePlayerSample Awake() call, GetNativeTextureID() is called on
renderer.material.mainTexture.
When the Oculus plugin gets the initialization event on the render thread,
it creates a new Android SurfaceTexture and Surface object in preparation
for receiving media.
When the game wants to start the video playing, it calls the StartVideoPlayerOnTextureId()
script call, which creates an Android MediaPlayer java object, issues a
native plugin call to tell the native code which texture id to put the video
on and return the Android Surface object to pass to MediaPlayer, then sets
up the media stream and starts it.
Every frame, right after VrApi::WarpSwap() is called by the native plugin,
the SurfaceTexture object is checked for updates. If there is one, the
target texId is re-created at the correct dimensions and format if it is
the first frame, then the video image is rendered to it and mipmapped.
The following frame, instead of Unity drawing the image that was placed
on the surface in the Unity editor, it will draw the current video frame.
It is important to note that the texture is actually replaced -- the original
version is gone, and the video will now show up everywhere that texture was
used, not just on sthe GameObject that ran the script.
NOTE: The resolution of the movie texture is hard coded to 960x540 in MediaSurface.cpp.
************************************************************************************/
public class MoviePlayerSample : MonoBehaviour
{
private int nativeTextureID;
bool startedVideo = false;
#if (UNITY_ANDROID && !UNITY_EDITOR)
bool videoPaused = false;
AndroidJavaObject mediaPlayer = null;
#endif
/// <summary>
/// Initialization of the movie surface
/// </summary>
void Awake()
{
Debug.Log("Awake");
if (GetComponent<Renderer>().material == null || GetComponent<Renderer>().material.mainTexture == null)
{
Debug.LogError("Can't GetNativeTextureID() for movie surface");
}
// This aparently has to be done at Awake time, before
// multithreaded rendering starts;
nativeTextureID = GetComponent<Renderer>().material.mainTexture.GetNativeTextureID();
Debug.Log("Movie Texture id: " + nativeTextureID);
}
/// <summary>
/// Auto-starts video playback
/// </summary>
void DelayedStartVideo()
{
if (!startedVideo)
{
startedVideo = true;
#if (UNITY_ANDROID && !UNITY_EDITOR)
// This can only be done once multithreaded rendering is running
mediaPlayer = StartVideoPlayerOnTextureId(nativeTextureID);
#endif
}
}
void Start()
{
#if (UNITY_ANDROID && !UNITY_EDITOR)
// delay one frame because OVRCameraController initializes the render thread in Start()
Invoke("DelayedStartVideo", 0.1f);
#endif
}
/// <summary>
/// Pauses video playback when the app loses or gains focus
/// </summary>
void OnApplicationPause(bool wasPaused)
{
Debug.Log("OnApplicationPause: " + wasPaused);
#if (UNITY_ANDROID && !UNITY_EDITOR)
if (mediaPlayer != null)
{
videoPaused = wasPaused;
mediaPlayer.Call(( videoPaused ) ? "pause" : "start");
}
#endif
}
#if (UNITY_ANDROID && !UNITY_EDITOR)
// This function returns an Android Surface object that is
// bound to a SurfaceTexture object on an independent OpenGL texture id.
// Each frame, before the TimeWarp processing, the SurfaceTexture is checked
// for updates, and if one is present, the contents of the SurfaceTexture
// will be copied over to the provided surfaceTexId and mipmaps will be
// generated so normal Unity rendering can use it.
[DllImport("OculusPlugin")]
private static extern IntPtr OVR_Media_Surface(int surfaceTexId);
#endif
#if (UNITY_ANDROID && !UNITY_EDITOR)
/// <summary>
/// Set up the video player with the movie surface texture id
/// </summary>
AndroidJavaObject StartVideoPlayerOnTextureId(int textureId)
{
Debug.Log("SetUpVideoPlayer ");
IntPtr androidSurface = OVR_Media_Surface(textureId);
c
AndroidJavaObject mediaPlayer = new AndroidJavaObject("android/media/MediaPlayer");
// Can't use AndroidJavaObject.Call() with a jobject, must use low level interface
//mediaPlayer.Call("setSurface", androidSurface);
IntPtr setSurfaceMethodId = AndroidJNI.GetMethodID(mediaPlayer.GetRawClass(),"setSurface","(Landroid/view/Surface;)V");
jvalue[] parms = new jvalue[1];
parms[0] = new jvalue();
parms[0].l = androidSurface;
AndroidJNI.CallObjectMethod(mediaPlayer.GetRawObject(), setSurfaceMethodId, parms);
mediaPlayer.Call("setDataSource", "/Card/oculus/Movies/Trailers/Interstellar.mp4");
mediaPlayer.Call("prepare");
mediaPlayer.Call("setLooping", true);
mediaPlayer.Call("start");
return mediaPlayer;
}
#endif
}
